Manufacturer
SUAM Schall- & Akustikmanufaktur GmbH
SUAM Akustikmanufaktur develops and manufactures custom room-acoustic elements made from thermally bonded polyester wadding in Bad Wünnenberg (North Rhine-Westphalia). The range covers ceiling rafts (rectangular, round, free-form), baffles, wall and ceiling absorbers, acoustic art panels, the dekaBel metal cassette absorber, and the modular free-standing screen. The PES core material is binder-free, fully recyclable and meets fire class B1 per DIN 4102. Certified to OEKO-TEX Standard 100 (test no. 94.0.0541).
WebsiteSUAM Baffle
Baffle
Description
The SUAM Baffle is a vertically suspended single baffle made of thermally bonded polyester wadding. It is used when the structural ceiling should remain visible or installation levels must remain freely accessible. Depending on the baffle spacing and installation height, sound absorption ranges between αw 0.50 (Class D) and αw 0.75 (Class C). A greater installation height improves low-frequency absorption. Mounting: Single suspension, cable suspension, direct mounting on T-profile, magnet, or system fastening. Customizable colors.
Technical data
Measurement data
Sound absorption
ISO 354 – reverberation chamber· 5 variants
Frequency values
αp per ISO 11654
| f (Hz) | 125 | 250 | 500 | 1k | 2k | 4k |
|---|---|---|---|---|---|---|
| αp | 0.35 | 0.55 | 0.70 | 0.95 | 1.00 | 1.00 |
Create a permanent free account — Access frequency bands, variants and export.
Free. No password required.
| Compare | Value | |
|---|---|---|
| baffle spacing 200 mm | αw0.75 | |
| baffle spacing 200 mm | αw0.60 | |
| baffle spacing 200 mm | αw0.60 | |
| baffle spacing 300 mm | αw0.60 | |
| baffle spacing 100 mm | αw0.50 |
Absorber class: C
Institute: SUAM intern (AkuLap Klasse 2, Dipl.-Ing. Antonius Sprenger-Pieper (SUAM))
Measurement date: 2024-01-27
Room volume: 146.5 m³
Object area: 9 m²
Dimensions: 200 × 3000 × 25 mm
